![](https://www.tvs-e.in/wp-content/uploads/2019/12/3mil-Resolution.png)
Enchanced high resolution sensor for
Rapid and precise scanning
High decoding ability to read damaged As well as low contrast codes bar codes
![](https://www.tvs-e.in/wp-content/uploads/2020/01/3-6.png)
Reads secure high density QR codes
![](https://www.tvs-e.in/wp-content/uploads/2020/01/1-1.png)
Superior barcode reading and image capture
![](https://www.tvs-e.in/wp-content/uploads/2019/12/Durable.png)
Built with high durability, designed to
Withstand 1.8 mts drop
![](https://www.tvs-e.in/wp-content/uploads/2019/12/IP42-ProtectioN.png)
IP 54 protection
Product Specification | Details |
---|---|
Scan mode | Handheld 2D Barcode Scanner |
Alarm node | LED light alarm, Buzzer alarm |
Scan rate | 60 frames/sec, 300 scans/sec |
Resolution | 1280 pixels (H) x 1024 pixels (W) |
Field of View | 39°(H)x28°(W) |
Scan angle | 360°(Roll), ±65°(Skew), ±65°(Pitch) |
Symbol contrast | >20% minimum reflective difference |
Barcode density | 4mil |
Light Source | (Aimer) Red color LED;(Illumination) White color LED |
Decode Ranges | Code39(5mil): 6-26cm Code39(13mil): 6-45cm QR(15mil): 7-25cm QR(20mil): 7-40cm QR(30mil): 7-60cm |
Barcode Type | 1D: Codabar, Code 39, Code 32 Pharmaceutical (PARAF), Interleaved 2 of 5, NEC 2 of 5, Code 93, Straight 2 of 5 Industrial, Straight 2 of 5 IATA, Matrix 2 of 5, Code 11, Code 128, GS1-128, UPC-A, UPC-E, EAN/JAN-8, EAN/JAN-13, MSI, GS1 DataBar Omnidirectional, GS1 DataBar Limited, GS1 DataBar Expanded, ChinaPost(Hong Kong 2 of 5), Korea Post. 2D: Codeblock A, Codeblock F, PDF417, GS1 Composite Codes, QR Code, Data Matrix, MaxiCode, Aztec, HANXIN. Default open: Codabar, Code39, Interleaved2of5, NEC2of5, Code93, Code128, GS1-128, UPC-A, UPC-E0, EAN/JAN-13, EAN/JAN-8, GS1-DataBar, PDF417, QR, DM, Aztec |
Voltage | DC+5V±5% |
Operating Power | 266mA(working); 130mA(standby); 210mA(Starting) |
Interfaces | USB, RS 232, USBCOM |
Electric Safety | En55022; 2006+A1: 2007 En55024: 1998+A1: 2001+A2: 2003 |
Shock Specifications | 2000G, 0.7ms, half sinus, 3 axes |
Operating temperature | -20 °C to 60 °C |
Storage Temperature | -30 °C to 70 °C |
Humidity | 5% to 95% relative humidity, non-condensing |
ESD | +/-8 kV contact discharge; +/-15kV air discharge |
Drop resistance | Designed to withstand 1.8m drops |
Dimensions (LxWxH) | 159.99mm*69.38mm*107.61mm |
Weight | 129.5g |
Material | ABS+PC |
Color | Black |
IP Rate | IP54 |
Ambient Light Immunity | 0-100000 Lux. |
USB cable | 1.8m |
